Printing Method |
Black & White Laser Beam Printing |
|
Fixing Method |
On Demand Fixing |
|
Print Speed |
Mono: A4 / Letter |
40 / 42ppm |
|
Duplex: A4 / Letter |
20 / 20.5ppm
(10 / 10.25spm; sheets/min.) |
|
Print Resolution |
600 x 600dpi
1200 x 1200dpi (equivalent)
2400 (equivalent) × 600dpi |
|
First Printout Time (FPOT) |
8.6 / 8.5 secs (A4 / Letter) |
Warm-Up Time
(From Power On) |
28 secs. or less |
Recovery Time
(From Sleep Mode) |
Sleep Mode 1 (Panel OFF): 0 sec.
Sleep Mode 2 (Engine Sleep): 10 secs.
Sleep Mode 3 (Deep Sleep): 10 secs. |
|
Page Description Language |
PCL5e/6, UFR II, PostScript 3, PDF, XPS |
|
|
|
Paper Input
(Based on 64g/m2) |
Standard Cassette: |
500 sheets |
|
Multi-Purpose Tray: |
100 sheets |
|
Optional Paper Feeder PF-45: |
500 sheets x 2 |
|
Maximum Paper Capacity: |
1,600 sheets |
Paper Output
(Based on 64g/m2) |
Face-Down: |
250 sheets |
|
Face-Up: |
50 sheets |
|
Paper Size |
Standard Cassette: |
A4 / B5 / A5 / A6 / Legal* / Letter / EXE / 16K / 8.5"×13"
Custom sizes (Width 105.0 - 215.9mm x Length 148.0 - 355.6mm)
* Legal refers to paper measuring 215.9 x 355.6mm (8.5 x14 inches) |
|
Multi-Purpose Tray: |
A4 / B5 / A5 / A6 / Legal* / Letter / EXE / 16K / 8.5"×13"
Custom sizes (Width 76.2 - 215.9mm x Length 127.0 - 355.6mm)
* Legal refers to paper measuring 215.9 x 355.6mm (8.5 x14 inches) |
|
Optional Paper Feeder PF-45: |
A4 /B5 / A5 / A6 / LGL* / LTR / EXE / 16K / 8.5"×13"
Custom sizes (Width 105.0 - 215.9mm x Length 148.0 - 355.6mm)
* LGL refers to paper measuring 215.9 x 355.6mm (8.5 x14 inches) |
|
Paper Weight |
Standard Cassette: |
60~120g/m2 |
|
Multi-Purpose Tray: |
60~199g/m2 |
|
Optional Paper Feeder PF-45: |
60~120g/m2 |
|
Paper Type |
Plain Paper / Heavy Paper / Transparency / Label / Index Card / Envelope |
|
Print Margins |
5mm-top, bottom, left and right
(Envelope: 10mm) |
|
Duplex Printing |
Standard (only A4 / LTR / LGL* / 8.5"×13")
* LGL refers to paper measuring 215.9 x 355.6mm (8.5 x14 inches) |
|
Paper Weight: |
60~120g/m2 |
|
|
|
|
Standard Interface |
USB: |
USB 2.0 High Speed, USB 2.0 Host (2 ports) |
|
Network: |
10Base-T / 100Base-TX / 1000Base-T |
|
Expansion Interface: |
SD Card Slot x 1 |
|
Compatible Operating Systems |
WindowsXP (32bit / 64bit), Windows Server 2003 (32bit / 64bit), Windows Vista (32bit / 64bit), Windows Server 2008 R2 (64bit), Windows Server 2008 (32bit / 64bit), Windows 7 (32bit / 64bit)
Mac OS X 10.5.8 and above *1, Linux*2, Citrix |
|
|
|
|
Device Memory |
768MB |
|
Optional ROM |
Barcode Printing Kit-F1 |
|
Standard Fonts |
93 Scalable, 136 PostScript fonts |
|
SD Card Option |
Canon SD Card-B1 (8GB) |
|
Operation Panel |
5 Line LCD |
|
Noise Level*3 |
During Operation: |
54.5dB or less (Sound Pressure Level)
7.3B or less (Sound Power Level) |
|
During Standby: |
Inaudible (Sound Pressure Level)
Inaudible (Sound Power Level) |
|
Power Consumption |
Maximum: |
1,400W or less |
|
During Operation: |
Approx. 660W |
|
During Standby: |
Approx. 15W |
|
During Sleep: |
Sleep Mode 1 (Panel OFF): Approx. 15W
Sleep Mode 2 (Engine Sleep): Approx. 5.4W
Sleep Mode 3 (Deep Sleep): Approx. 1.0W |
|
Energy Star TEC (Typical Electricity Consumption) |
1.9kWh/week |
|
Dimensions (W × D × H) |
454 x 424 x 345mm |
|
Weight |
Approx. 16.6kg (Without Cartridge) |
|
Power Requirements |
AC 220 - 240V (±10%), 50 / 60Hz (±2Hz） |
|
Operating Environment |
Temperature: |
10~30°C |
|
Humidity: |
20~80% RH (No Condensation) |
|
Toner Cartridge*4 |
Cartridge 324: |
6,000 pages |
|
Cartridge 324 II: |
12,500 pages*5 |
|
Monthly Duty Cycle*6 |
100,000 pages |
|
Recommended Monthly Print Volume |
1,500 - 5,000 pages |
