Printing Method |
Colour Laser Beam Printing |
|
Fixing Method |
On Demand Fixing |
|
Print Speed |
Simplex: |
Mono: 32/33ppm (A4 / Letter)
Colour: 32/33ppm (A4 / Letter) |
|
Duplex: |
27.6/28.9ppm
13.8/14.5spm (sheets/min) |
|
Print Resolution |
600 × 600dpi |
|
9600 (equivalent) × 600 dpi |
|
First Printout Time (FPOT) |
Mono: |
10.2secs. (A4/Letter) |
|
Colour: |
10.4secs. (A4/Letter) |
|
Warm-up Time (from Power On) |
39secs. or less |
|
Recovery Time |
From Engine Sleep: |
Approx. 7secs. |
|
From Deep Sleep: |
Approx.30secs. |
|
Print Language |
UFR II, PCL5c/6, Postscript 3, PDF, XPS |
|
|
|
|
Paper Input (based on 80g/m2) |
Standard Cassette: |
500 sheets |
|
Multi-Purpose Tray: |
100 sheets |
|
Optional Paper Feeder (PF-723A): |
500 sheets |
|
Maximum Paper Capacity: |
1,100 sheets |
|
Paper Output (based on 80g/m2) |
200 sheets (Face-Down) |
|
Paper Size |
Standard Cassette: |
A4 / B5 / A5 / A6 / Letter / Executive / 16K / Statement /
Custom (Width: 101.6~215.9(*1)mm x Length: 148~297.0(*2)mm)
(*1): when width is 215.9mm, max length is 279.4mm
(*2): when length is 297.0mm, max width is 210.0mm |
|
Multi-Purpose Tray: |
A4 / B5 / A5 / A6 / Letter / Legal* / Executive / Foolscap / 16K / Statement / Envelope COM-10 / Envelope C5 / Envelope Monarch / Envelope DL / 3 x 5 index card /
Custom (Width: 76.2 ~ 215.9mm x Length: 127.0 ~ 355.6mm)
* Legal refers to paper measuring 215.9 x 355.6mm (8.5 x14 inches) |
|
Optional Paper Feeder (PF-723A): |
A4 / B5 / A5 / Letter / Legal* / Executive / Foolscap / 16K /
Custom (Width: 148 ~ 215.9mm x Length: 210.0 ~ 355.6mm)
* Legal refers to paper measuring 215.9 x 355.6mm (8.5 x14 inches) |
|
Paper Weight |
Standard Cassette: |
60~163g/m2 |
|
Multi-Purpose Tray: |
60~216g/m2 |
|
Optional Paper Feeder (PF-723A): |
60~176g/m2 |
|
Paper Type |
Plain Paper / Heavy Paper / Transparency / Recycled Paper / Label / Envelope |
|
Print Margins |
5mm-top, bottom, left and right (Envelope: 10mm) |
|
Duplex Printing |
A4 / B5 / A5 / Letter / Legal* / Executive / Foolscap / 16K /
Custom (Width: 148.0 ~ 215.9mm x Length: 210.0~355.6mm)
Recommended Paper Weight: 60 - 163g/m2
* Legal refers to paper measuring 215.9 x 355.6mm (8.5 x14 inches) |
|
|
|
|
Standard Interfaces |
USB: |
USB 2.0 High Speed
USB 2.0 (Host x 2) |
|
Network: |
10Base-T/100Base - TX/1000Base-T |
|
Expansion Interface: |
SD Card Slot |
|
Compatible Operating Systems |
Windows: |
Windows XP (32bit / 64bit) / Windows Server 2003 (32bit / 64bit) /Windows Vista (32bit / 64bit) / Windows Server 2008 (32bit / 64bit) / Windows 7 (32bit / 64bit) |
|
Macintosh: |
Mac OS 10.5.8 and above*1 |
|
Linux |
|
Citrix |
|
|
|
|
Device Memory |
768MB |
|
Optional ROM |
Barcode Printing Kit-F1 |
|
Standard Fonts |
93 Scalable, 10 Bitmap fonts, 136 PostScript fonts |
|
SD Card |
Canon SD Card-B1 (8GB) |
|
Operation Panel |
5 Line LCD
12 Keys, 8 LEDs |
|
Noise Level*3 |
During Operation: |
7.0B or less (Sound Power)
Approx. 52dB (Sound Pressure) |
|
During Standby: |
5.3B or less (Sound Power)
Approx. 32.4dB (Sound Pressure) |
|
Power Consumption |
Maximum: |
1,270W or less |
|
During Operation: |
Approx. 580W |
|
During Standby: |
Approx. 35W |
|
During Sleep: |
Approx. 1W |
Energy Star TEC
(Typical Electricity Consumption) |
1.6kWh/week |
|
Dimensions (Width x Depth x Height) |
517 x 530 x 401mm |
|
Weight (without Cartridge) |
Approx. 31.5kg (Without Cartridge) |
|
Power Requirements |
220 - 240V, 50/60Hz (±2Hz) |
|
Operating Environment |
Temperature: |
10 ~ 30°C |
|
Humidity: |
20 ~ 80%RH (No Condensation) |
|
Toner Cartridge*4 |
Cartridge 332 Black: |
6,100 pages |
|
Cartridge 332 II Black: |
12,000 pages |
|
Cartridge 332 CMY: |
6,400 pages |
|
Waste Toner Box |
WT-723: |
18,000 pages |
|
Monthly Duty Cycle*5 |
75,000 pages |
|
Recommended Monthly Print Volume |
1,250 - 5,000 pages |
